IP503H
IP503H
- Description
- Performance Characteristics
- Physical Characteristics
- User Environment
Instant Wide Area Coverage Over a LTE (4G) and 3G Network
The IP503H provides wide area communication using a LTE (4G)
and 3G network and instantaneous communication.
Individual calls, Group calls or All calls can be made the same way
as a conventional two-way radio.
Full-Duplex Communication
The IP503H enables use of full-duplex communication which provides smooth telephone style conversations. The IP503H users can talk and receive at the same time.
Multiple User Communication
Multiple users in the call groups can initiate calls instantaneously. Removing the need to wait for available channels to communicate.
Priority Interrupt Calling
The IP503H supports group calls with three or more people. In case of an emergency, you can break into an on-going call to transmit an important message.
Frequency band:
3G and 4G Bands
Power Output:
200 mW
Standard battery chemistry type:
Lithium Ion
Battery life (based on a 5-5-90 duty cycle):
More than 17 hours
Dimensions W x H x D (with standard battery)
2.3 × 3.7 × 1.3 in
Weight (with standard battery)
8.5 oz
Keypad / Keys
Limited
Display
Full
Operating temperature
+14 °F to +140 °F
Mil spec
810G
IP Standards
IP67/55/54
Industry Leading Compact and Lightweight Body
Compact 59 × 95 × 32 mm; 2.3 × 3.7 × 1.3 in and 240 g; 8.5 oz (approximate) lightweight body* allows non-intrusive mobility and use.
* With BP-272 battery pack and antenna. Projections are not included.
IP67 Dust-Tight and Waterproof
The IP503H has been designed to preserve its waterproof integrity in water of a depth of 1 meter for 30 minutes. It can be used for outdoor work or places prone to get wet.
Optional Charger Cradle With Bluetooth® Function
When the optional BC-218, charger cradle and HM-215, speaker-microphone is used, calls can be made with the microphone, while charging the IP503H. Even when the IP503H is not dropped into the BC-218, the Bluetooth® function enables you to wirelessly use the speaker-microphone.
Powerful and Clear Audio
The powerful 900mW speaker provides high-quality and clear audio, even in noisy environments.
Other Features
- Individual, Group, Talkgroup, Multiplex Talkgroup and All calls
- Emergency button, Lone Worker and Man Down functions
- Vibration alert function notifies of incoming call
- Text message reception and preprogrammed message transmission
- Up to 500 memory address book (including Group, Individual, Talkgroup and Telephone lists)
- Voice message recording
- Built-in Bluetooth® and GPS
- RoIP Gateway VE-PG4
No Accessories List at present
Please Contact Us for more information
